Description
- 24 Individual outputs/12 shutter channels
- Supports two-pipe fan coil control for cooling (on/off valve and fan speed control for FCU)
- Manual output operation with push-button and LED status indicator
- 10 Scene functionality
- In-built thermostat functionality
- Enables one-channel ceiling fan control using 4 relays and the EX-CFC-1 module
- Logic functions, last scene recall & data recovery
- Lock / unlock functionality for secure operation
- Possibility of connecting different phases in different outputs
- Programming button and LED indication
- Timer and pulse functionality
- Output relay rating: 16A / 250V AC
- Rated output current: 16A @ 277V AC (4,432 VA)
- Maximum inrush current: 100 A (resistive load)
- Outputs per common: 1 output (switching) 2 outputs (shutter)
- Dimension: 213 (L) x 90.5 (H) x 62 (D) mm (12 DIN Unit)
