MES-DICE23

Timeless and Future-proof Technology

Limitless Potential

Two 16A outputs, 3 inputs, in a compact assembly to be mounted ideally in a switch metal box. A preferred solution for last minute circuit additions or when wiring is a constraint at site. Inputs can be used to bring KNX operability over conventional switches, motion sensor, door/window contacts, temperature sensors.

Product Enquiry
Category:

Description

  • 2 Individual outputs /1 Shutter Channels
  • 3 Digital and analog inputs
  • Manual output operation with push button and LED status indicator
  • 10 Scene functionality
  • Last scene recall and data recovery
  • Lock / unlock functionality for secure operation
  • Timer and pulse functionality
  • Logical functions included
  • Possibility of connecting different phases in different outputs
  • Programming button with LED indication
  • Dimension: 50.5 (L) X 55.5 (H) X 34.1 (D) mm
  • Output relay rating: 16A / 250VAC
  • Rated output current: 16A @ 277V AC (4,432 VA)
  • Maximum inrush current: 100A (resistive load)
