Description
- 16 individual outputs or 8 shutter channels
- Supports one two-pipe fan coil control for cooling (on/off valve and fan speed control for FCU)
- 10-scene functionality
- Enables one-channel ceiling fan control using 4 relays and the EX-CFC-1 module
- Last scene recall and data recovery
- Manual output operation with push-button and LED status indicator
- In-built thermostat functionality
- Allows connecting different phases for different outputs
- Includes logical functions
- Output relay rating: 16A / 250V AC
- Rated output current: 16A @ 277V AC (4,432 VA)
- Maximum inrush current: 100 A (resistive load)
- Outputs per common: 1 output (switching) 2 outputs (shutter), 4 Outputs (Fan)
- Dimensions: 142.3 (L) x 90.5 (H) x 62 (D) mm (8 DIN units)
